RAID setting
Notice:
Data will be deleted when RAID is set up,
please backup your data first!
There are 4 RAID modes on the device
The factory default is JBOD mode
Use the switch on the device to change the RAID mode
Note: The white position represents
the switch
RAID 0: Recognize one drive and the capacity is twice the smaller hard disk's
Example: 1000GB+750GB=1500GB
Setting: Set the two switches to the position of numbers
Note: If any hard disk fails, all data will be lost
RAID 1: Recognize one drive and the capacity is the smaller hard disk
Data will be backuped to another hard disk at the same time
Example: 1000GB+750GB=750GB
Setting: Set No.1 Switch to the position of "ON" Set No.2 Switch to the
position of number
Note: If any hard disk fails, all data will be lost
SPAN: Recognize one drive and the capacity is the sum of the two hard disks
Example: 1000GB+750GB=1750GB
Setting: Set both switches to the position of "ON"
Note: The computer will be recognized as a large hard drive
JBOD: Recognize two hard drives (factory default setting mode)
Setting: Set No.1 Switch to the position of number, Set No.2 Switch to the
position of "ON"
Note: The computer will be recognized as two independent hard drives
If only one hard disk is used, please set to this mode
