ACCU-Pro 670 - Page 41

41
PARTS LIST (Continued) 6609529 GRINDING HEAD ASSEMBLY
DIAGRAM
NUMBER
PART
NUMBER
PART
DESCRIPTION
1...............B190611...............10 - 24 x 3/8 Socket Head Cap Screw
2...............B191213...............10 - 24 x 3/4 Button Head Socket Cap Screw
3...............B250816...............1/4 -20 x 1/2 Button Head Socket Cap Screw
4...............B251216...............1/4 - 20 x 3/4 Button Head Socket Cap Screw
5...............B251616...............1/4 - 20 x 1 Button Head Socket Cap Screw
6...............B252016...............1/4 - 20 x 1 - 1/4 Button Head Socket Cap Screw
7...............B371211............... 3/8 - 16 x 3/4 Socket Head Cap Screw
8...............C190820...............10 - 24 x 1/2 Socket Set Screw
9...............C250420...............1/4 - 20 x 1/4 Socket Set Screw
10.............C250820...............1/4 - 20 x 1/2 Socket Set Screw
11.............C310420...............5/16 - 18 x 1/4 Socket Set Screw
12.............C621060...............5/8 - 18 x 5/8 Socket Set Screw
13.............J377000...............3/8 - 16 Locknut Jam Nylon
14.............K190001...............No. 10 Flat Washer
15.............K191501...............No. 10 Lockwasher Split
16.............K251501...............1/4 Lockwasher Split
17.............K371501...............3/8 Lockwasher Split
18.............3589081...............Spacer
19.............K310101...............5/16 Flat Cut Washer
20.............3700409...............Bushing - Reducer
21.............3700411...............Grinding Wheel Straight Cup 6" dia x 2" deep
22.............3702086...............Diamond Dresser
23.............3708121...............Clamp - Double Tube
24.............3708543...............Shoulder Bolt
25.............3708553...............Spring Compression
26.............3708561...............Adjustable Handle
27.............3708657...............Roller Dual Vee
28.............3708658...............Spring Compression
29.............3709062...............Washer Conical
30.............3709304...............Washer - Thrust
31.............3709526..............Knob
DIAGRAM
NUMBER
PART
NUMBER
PART
DESCRIPTION
32.............3708103...............Washer Conical
33.............3709705..............Nylon Ball
34.............3809047...............Indicator Clear
35.............6009023...............Shaft Adjusting
36.............6059082...............Ring Calibrated
37.............6009044...............Handwheel
38.............6609004...............Base Carriage Slide
39.............6609027...............Arm - Roller Pivot
40.............6609028...............Bushing-V Roller Short
41.............6609029...............Bracket - Dresser Lock
42.............6609030...............Guide - Feed Screw
43.............6609058...............Bushing-V Roller Long
44.............6709035...............Stud
45.............3707009...............Strain Relief
46.............6609502...............Motor Assy 3/4 HP
47.............3708448...............Decal Warning Electrical
48.............3708458...............Decal Warning Sharp
49.............3708461...............Decal Warning 3600 RPM
50.............6609505...............Motor Pivot Assy
51.............6709038...............Collar - Adjuster
52.............6709103...............Flange - Outer
53.............6709501...............Tee Knob Assy
54.............6709503...............Eccentric Pin Assy
55.............6709509...............Dresser Arm Weldment
56.............6709552...............Grinding Wheel Guard Weldment
58.............B255011...............
Socket Head Cap Screw 1/4-20 x 3-1/8Long
59.............3709370...............Handle
60.............J252000...............Hex Jam Nut 1/4 - 20
61.............J257000...............1/4 - 20 Nylok Lock Nut
