ACCU-Pro 670 - Page 43

43
PARTS LIST (Continued) 6709531 TRAVERSE & CARRIAGE ASSEMBLY
DIA. NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
PART NO.
B191233
B250801
B251017
B251611
B251811
B311001
B371201
J251000
K190001
K191501
K250001
K251501
K310001
K311501
K370001
K371501
3589081
3619224
3708046
3708147
3708454
3708457
3709183
3709583
3709613
3709635
3849239
3969032
6009068
6009070
6709146
6709148
6009108
6009109
6009152
6009153
6009155
6009198
6009548
6009549
6009572
B191011
B190811
B252211
K251501
3559117
3709040
3709044
6709147
3969064
28211
3709668
3709597
3709596
3709469
B253211
3708691
J197000
6709039
6709149
B311001
DESCRIPTION
Phillip's Head Machine Screw 10-32 x 3/4
Hex Head Cap Screw 1/4-20 x 1/2
Round Head Machine Screw 1/4-20 x 5/8
Socket Head Cap Screw 1/4-20 x 1
Socket Head Cap Screw 1/4-20 x 1-1/8
Hex Head Cap Screw 5/16-18 x 5/8
Hex Head Cap Screw 3/8-16 x 3/4
Hex Nut 1/4-20
Flat Washer #10
Split Lockwasher #10
Flat Washer 1/4
Split Lockwasher 1/4
Flat Washer 5/16
Split Lockwasher 5/16
Flat Washer 3/8
Split Lockwasher 3/8
Spacer .191ID x .438OD x .43L
Compression Spring
Grommet
Shoulder Bolt .375D x .625L
Warning Decal - Release Actuator
Warning Decal - Hot Surface
Wiper Seal
Flexible Coupling
Star Knob 5/16-18
Pillow Block Brearing
Carriage Drive Shaft
Seal Mount
Proximity Support Rail
Proximity Bracket
Proximity Sensing Bracket
Rubber Pad
Left-hand Traverse Proximity Switch
Right-hand Traverse Proximity Switch
Shaft Collar
Rubber Washer
Modified Release Actuator
Traverse Motor Assembly
Actuator Bar Assembly
Release Arm Weldment
Proximity Rail Weldment Clamp
Socket Head Cap Screw 10-24 x 5/8
Socket Head Cap Screw 10-24 x 1/2
Socket Head Cap Screw 1/4-20 x 1 3/8
Split Lockwasher 1/4
Carrier Shaft
Spherical Bearing
Bushing Ball Bearing
Carriage Base
Sponge Wiper
Sponge Wiper Holder
Socket Head Screw
Sealed Bearing
Spacer
Compression Spring
Socket Head Cap Screw 1/4-20 x 2
Flat Washer
Locknut 10-24
Rubber Cover Bracket
Rubber Cover
Hex Head Cap Screw 5/16-18 x 5/8 Long
