45
PARTS LIST (Continued) 6709533 BEDKNIFE SUPPORT ASSEMBLY
DIA. NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
PART NO.
B190411
B190605
B191011
B191611
B250611
B251211
B253611
B371611
C190420
C310420
6709162
H250802
H251202
H251406
H251802
K310101
H251602
J371000
J377000
J377100
J507000
K191501
K250001
K251501
K371501
3579109
6709142
6709519
3708245
3708393
3708554
3708563
3708564
3708330
3708702
3708694
6709135
3708701
3708581
3709016
3709062
3709304
6009035
6009036
6009095
6709004
6709532
6709107
6709008
6709011
6709012
6709013
6709015
6709164
6709021
6709134
6709151
6709108
6709136
6709152
6709501
6709556
3708593
6709556
B251411
3708691
B371211
C250627
B191211
09054
6709163
K250101
K250611
K500001
2109096
DESCRIPTION
Socket Head Cap Screw 10-24 x 1/4
Flat Head Socket Cap Screw 10-24 x 3/8
Socket Head Cap Screw10-24 x 3/8
Socket Head Cap Screw 10-24 x 1"
Socket Head Cap Screw 1/4-20 x 3/8
Socket Head Cap Screw 1/4-20 x 3/4
Socket Head Cap Screw 1/4-20 x 2-1/4
Socket Head Cap Screw 3/8-16 x 1
Set Screw Cup Point 10-24 x 1/4
Set Screw Cup Point 5/16-18 x 1/4
Shaft - Gage Spring Retainer
Roll Pin .25D x .50LG
Roll Pin .25D x .75LG
Drive Lock Pin .25D x .875LG
Roll Pin .25D x 1.125LG
Flat Washer 5/16
Roll Pin .25D x 1.00LG
Hex Nut 3/8-16
Nylon Locknut Jam 3/8-16
Nylon Hex Locknut 3/8-16
Nylon Locknut 1/2-13 thin
Split Lockwasher #10
Flat Washer 1/4
Split Lockwasher 1/4
Split Lockwasher 3/8
Nylon Plug 3/16 Diameter
Electromechanical Actuator
Pivot Bearing Assembly
T-Knob 2.5 3/8-16F
Handwheel 3.5 Diameter
Compression Spring .6250D x 3.0L
Retaining Extension Ring 5100-118
Oilite Thrust Bearing 1.25ID
Shoulder Bolt .50D x 4.0L
Button Head Socket Cap Screw M3-.5 x 30
Linear Bearing Wide
Rail Bellows 25/70
Button Head Socket Cap Screw M3-.5 x 16
Inch Dial Indicator
Thrust Washer
Conical Washer .382 x .75 x .035
Thrust Washer
Locking Stud Shaft
Acme Adjusting Shaft
Slide Shaft
Machined Tooling Bar
Tooling Mounting Bracket Assembly
Tooling Slide Mounting
Left-hand Pivot Plate
Index Stop Bracket
Right-Hand Gage Base
Left-Hand Gage Base
Retainer Block Gage
Gage Shaft
Gage Tip
Bearing Block Lock Block
Decal - Upper Tooling Index
Cross Slide Support
Wide Machined Rail 25/70
Decal - Lower Tooling Index
Tee Knob Assembly
Magnet Repair Assembly - INA
Key 5/16 SQ x 1/2
Magnet Repair Assembly - INA
Socket Head Cap Screw 1/4 -20 x 7/8
Washer .25 x .62 OD x .12
Socket Head Cap Screw 3/8 - 16 x 3/4
Set Screw Cap Point 1/4 -20 x 3/8
Socket Head Cap Screw 10-24 x 3/4
3/8 ID x 5/8 OD X 1/16 Thick Flat Washer
Flag - Gage Shaft
Washer - Flat .31 x .73 x .052T
Socket Head Cap Screw 1/4 - 20 x 3/8
Washer - Flat 1/2
Spacer .50 ID x 1.00 OD x .50 L
