PARTS LIST (Continued) 3708784 COOLANT PUMP/TANK ASSEMBLY

1 ........................................... 3709642 ................... Swivel Nozzle

2 ........................................... 3679116 ................... Connector Shut - Off Valve

3 ........................................... K190001................... #10 Flat Washer

4 ........................................... B191611 ................... 10-24 x 1 Socket Head Cap Screw

5 ........................................... K191501................... #10 Lockwasher Split

6 ........................................... 3709595 ................... Shut Off Valve

7 ........................................... 3709593 ................... Barbed Connector

8 ........................................... 3707532 ................... Pump 115V

9 ........................................... 3708339 ................... Connector - Barbed Insert

10 ......................................... 3708725 ................... Tank - Coolant

11 ......................................... 3708774 ................... Cover - Coolant Tank

12 ......................................... 3708775 ................... Divider - Coolant Tank 5”

13 ......................................... 3708778 ................... Divider - Coolant Tank 6.5”

14 ......................................... 3708785 ................... Instruction Sheet - Coolant Tank

15 ......................................... 3389039 ................... Coolant Hose

DIAGRAM

NUMBER

PART

NUMBER

DESCRIPTION
