4. Operation (cont.)
4.3 Bill Positioning
- This equipment has the ability to verify the authenticity of bills in any
of four positions.
- For correct verification, the bill must be introduced into the feeding
channel straight and well-aligned to the left edge, as shown in Figures
"A" and "B".
- Avoid introducing the bill into the feeding channel separated from
the left side and/or at an angle, as shown in Figure "C".
