18
Program
A. Foot stimulation program
B. Body stimulation program
Phase
Number
Frequency
(Hz)
On
time
(s)
Off
time
(s)
Cycle
Time
(s)
1) Time: 1~99 minutes
2) Frequency:
10Hz~36Hz
3) Pulse width: 250us
4) On time: 1.9s~10.6s
5) Off time: 1.0s~3.7s
6) Cycle Time:
3.5s~11.6s
1 10 3.4 1.0 4.4
2 12.5 7.2 1.0 8.2
3 20 6.4 1.0 7.4
4 36 2.1 2.1 4.2
5 16.6 4.4 1.5 5.9
6 10 4.7 1.0 5.7
7 36 1.9 1.6 3.5
8 12.5 4.3 1.1 5.4
9 10 3.7 3.7 7.4
10 20 9.2 1.0 10.2
11 31 2.2 1.5 3.7
12 22 10.6 1.0 11.6
13 16 5.1 1.0 6.1
14 20 6.7 1.0 7.7
15 22 7.6 1.1 8.7
Program Description
1) Time: 1~99 minutes
2) Frequency: 20Hz
3) Pulse width: 200us
4) On time: 11s
5) Off time: 5s
6) Duty cycle: 16s
The pulses take 3 seconds from zero to 12
pulses and stays for 5 seconds, and then
takes 3 seconds from 12 pulses to zero; then
the device stops output for 5 seconds. The
device repeats this cycle during the treatment
time. The output frequency is 20Hz and the
pulse width is 200us.
