DC Inverter U-match Series for R410A Unitary Split Air Conditioner
22
⑧
When connecting the power cords, make sure the phase sequence of the
power supply matches with the corresponding terminals, otherwise the
compressor will get reversed and operate abnormally.
Remove the big handle/front panel of the outdoor unit and insert one end of the
thermostat cord and the power cord to the terminal board.
Single-phase unit: FXD-ACD36
