ACE146
I/O Connections
Location: There are three locations on the VS-S660I that have I/O connections.
(1) The rear of the chassis (integrated into the motherboard)
(2) The front of the chassis (integrated into the chassis front panel)
(3) The rear of the chassis (integrated into the graphics card, as applicable)
Note: There is no graphics card installed in this system, but the I/O
connections would be located in the space noted above.
Procedure:
Note: I/O connections are integral parts of higher-level assemblies and thus to replace them the
entire assembly would need to be replaced.
To uninstall/reinstall any of the I/O connections refer to the sections below:
(1) Motherboard Section (page 24-25).
(2) Chassis Section (page (page 11)
(3) Expansion Card/Graphics Card Section (page 20-21).
Graphics Card I/O
Connections
Font Panel I/O
Connections
Motherboard I/O
Connections
