Installation 3
FINDING THE DEPTH OF YOUR WELL
(For cased shallow wells only)
Tie a small but heavy weight to the end of a piece of string.
Lower the weight into the well until it reaches the bottom.
Take up the slack and mark the string at ground level. Pull
the weight out of the well and measure from the bottom of the
weight to the ground level mark. This is the depth of your well.
Subtract five feet from the depth of your well. This number
should not exceed 25 feet. If it does, it will greatly hinder or
prevent the proper operation of a lawn sprinkler pump.
SPECIFICATIONS
FUSE/BREAKER & WIRE SELECTION GUIDE
PUMP CAPACITIES
Pump
Model HP
Discharge
Pressure
PSI
Capacity in GPM for Discharge Pressure and Total
Suction Lift Indicated Maximum Total Shut Off Hd.
Approx.
Wt. Lbs.10 Ft. 15 Ft. 20 Ft. 25 Ft. Feet PSI
ESP-75A .75
15 42 38 36 26
103 45 49
20 37 34 32 25
25 32 29 27 24
30 27 23 20 12
35 18 10 —
ESP-100A 1. 0
15 48 45 37 27
106 46 49
20 45 42 36 26
25 40 37 34 25
30 33 30 26 20
35 25 20 — —
ESP-150A 1. 5
15 51 48 41 29
106 46 52
20 48 45 40 28
25 43 42 37 27
30 37 35 31 26
35 26 22 — —
ESP-200A 2.0
15 62 53 44 33
107 46 63
20 61 52 43 32
25 60 51 41 31
30 52 48 39 30
35 43 36 27 —
NOTE: Performance will be reduced slightly by the foot valve; but the use of a foot valve is recommended.
PIPING
Plastic PVC pipe is shown in the illustrations, but galvanized
steel pipe may be used if desired. All piping must be clean
and free of all foreign matter to prevent clogging. ALL JOINTS
AND CONNECTIONS IN THE WELL ASSEMBLY MUST
BE AIRTIGHT. Even a pinhole leak will prevent the proper
operation of the pump (this is the most common problem).
Use thread compound on all threaded joints unless specified
otherwise.
Pump
Model Motor HP Volts
Max.
Load
Amp
Fast
Acting
Fuse
Slow
Acting
Fuse
Circuit
Breaker
Max. Wire Length per Wire Gauge - feet
14 Ga. 12 Ga. 10 Ga. 8 Ga.
ESP-75A 0.75 115 14.8 25 20 20 0 140 220 355
ESP-75A 0.75 230 7. 4 15 10 10 350 560 895 1420
ESP-100A 1 115 14.8 35 25 30 0 0 150 245
ESP-100A 1 230 7. 4 20 15 15 240 385 615 975
ESP-150A 1. 5 115 19.9 40 30 35 0 0 130 210
ESP-150A 1. 5 230 9.95 20 15 20 205 330 530 835
ESP-200A 2 115 24 15 10 10 175 280 445 710
