Acea NovoCyte - Page 3

3
Opcal Conguraon Opon 1
Detector BP Filter Dichroic Mirror
Laser
405 nm 488 nm 640 nm
1 445/45 472SP Pacic Blue
2 530/30 505LP AmCyan FITC
3 572/28 555LP Pacic Orange PE
4 660/20 650LP Qdot 655 PE-Cy5 APC
5 695/40 685LP Qdot 705 PE-Cy5.5 Alexa Fluor 700
6 780/60 735LP Qdot 800 PE-Cy7 APC-Cy7
14 FL Channels
6 5 3
Opcal Conguraon Opon 2
Detector BP Filter Dichroic Mirror
Laser
405 nm 488 nm 640 nm
1 445/45 472SP Pacic Blue
2 530/30 505LP AmCyan FITC
3 660/20 650LP Qdot 655 PE-Cy5 APC
4 695/40 685LP Qdot 705 PE-Cy5.5 Alexa Fluor 680
5 725/40 705LP BV711 PerCP-eFluor 710 Alexa Fluor 700
6 780/60 757LP Qdot 800 PE-Cy7 APC-Cy7
15 FL Channels
6 5 4
