Acea NovoCyte - Page 7

7
Opcal Conguraon Opon 1
Detector BP Filter Dichroic Mirror
Laser
488 nm 640 nm
1 530/30 505LP FITC
2 572/28 555LP PE
3 660/20 650LP PE-Cy5 APC
4 780/60 735LP PE-Cy7 APC-Cy7
6 FL Channels
4 2
Opcal Conguraon Opon 2
Detector BP Filter Dichroic Mirror
Laser
488 nm 640 nm
1 530/30 505LP FITC
2 660/20 650LP PE-Cy5 APC
3 695/40 685LP PE-Cy5.5 Alexa Fluor 700
4 780/60 735LP PE-Cy7 APC-Cy7
7 FL Channels
4 3
