Fig.2 Fig.3
Fig.4
Accordion Panel Installation
Now that you have installed the top rail, you can now install the accordion panels on
each side.
Place the air conditioner on a hard flat surface.
Locate the accordion panels in the box.
Gently pull the free end of the accordion panel (See Fig.2). Do this for both panels.
Slide the free end of the accordion panel into the side panel of the air conditioner (See
Fig.3). Do this for each side.
Once the accordion panels are slid into place adjust the top and bottom rails of the
accordion panels into the top and bottom rails of the air conditioner (See Fig.4).
Your home in sync
08
