Fig.11 Fig.12
Fig.13 Fig.14
Drive 1/2" screws into the top of the accordion panel frame and the top rail to securely
attach the window air conditioner to the lower sash. (See Fig.11 Fig.12)
To secure the lower sash into place, use the sash lock and a 3/4" screw as shown
below. (See Fig.13)
For added insulation, cut the supplied insulation foam to the width of the window.
Insert the foam between the window sashes to prevent air and objects from getting
into the room. (See Fig.14)
