Chapter 3 59

3. Remove the antenna cable from the board.

4. For Aspire 8730/8730Z Series, remove the one screw (B) securing the board to the system.

Step Size (Quantity) Color Torque

1 M2 x L4 (1) Silver 1.6 kgf-cm
