MICHANICAL PARTS
CKT_ID Component Description Pri
6FB1 7742807870P0A PUSH BUTTON_#6780#6790_ABS_UL94HB_ACER_ R20BUNW-M1
6FC1 7742807880P0A PUSH BUTTON_KEY PW_#6780#6790_ABS_UL94HB ACER_R20BUNW-M1
6L01A 7742613400P0A COVER_HINGE_#6800_ABS_UL94HB_ACER_R20BUN W-M1
6L01B 7111230061P SCREW-MACHINE-Flat Washer-Pan-M3-6-Zn
6L01C 7116240081P0A SCREW-MACHINE-Star Washer-Pan-M4-8-Zn
6L01D 7110330052P0A SCREW-MACHING-FLAT HEAD-M3-5-NI
6L01E 7140330083P0A SCREW-DOUBLE THREAD-NO WASHER-FLAT HEAD
6L01F 7110730082P0A SCREW_MACHINE_NONE_HEX WASHER HEAD_M3_8m m_Fe NI
6L01G 7140130061P0A SCREW_MACHINE_WITHOUT_NINDING_M3_6L_BLA
6L01H 7115240121P0A SCREW_M4*12_DOUBLE WASHIER
6L01I 7110330052P0A SCREW-MACHING-FLAT HEAD-M3-5-NI
8C01 7742612091P0A STAND_COVER_#6800_ABS 94HB_ABS 94HB_ACER R17BNW
8C03 7738001840P0A HINGE_STAND_WHT_SUS430 T=2.0mm_ACER_ T17AN/BNHW
8C04 7140340162P0A SCREW_DOUBLE THREAD_NONE_FLAT HEAD_M4x16 mm_NI
8CA2 7740412200P0A STAND_BASE_ACER_AL1717_#6800_ABS 94HB ACER 17
D809N 7110430081P SCREW-MACHINE-Binding-M3-8-Zn
D810N 7110430081P SCREW-MACHINE-Binding-M3-8-Zn
G801 7748000190P0A GROUNDING_CONNECTOR_MTS_C150AT_PHOSPHOR
Q803N 7110430081P SCREW-MACHINE-Binding-M3-8-Zn
PARTS & MISCELLANEOUS PARTS
CKT_ID Component Description Pri
6F01T 7742005280P0A SPONGE_GASKET FORM_WHT_W10xH10xL40mm
6FD1 7742302790P0A LENS_KEY_CLEAR_PC_UL94HB_ACER_R20BUNW-M1
8C02 7737717850P0A BASE ASSY_#6800_ABS 94V0_ACER_T17BNHW
8CB2 7742004160P0A RUBBER CUSHION_FOOT PAD_SILICONE_BLACK
D809M 7746402831P0A HEAT SINK_HEAT SINK_B17MTF_AL_CLEA
F801 6851002050P00 FUSE_TIME LAG_2A/250V_215002MXP_LITTELFU SE
F801E 6622050010P FUSE CLIP_FC
PC01 6716004833P CABLE_POWER_1800mm_CPQ:268246/HP& CPQ:8121-0731_BLACK_LONGWELL
PARTS & MISCELLANEOUS PARTS
CKT_ID Component Description Pri
Q803M 7746402681P0A HEAT SINK_K17ANU_AL_6063
V200 6814175010P14 LCD_17"W_HSD170MGW1-A00(LTC) _HSD_1370g
X301 6449006400P CRYSTAL_14.318MHz_AT_49_TOPICS
Y001 7730303323P0A MANUAL ASSY_ACER_T17AN_AL1716W_EMEA_27L
Y002 7730203550P0A CARD_SCREEN PROTECTOR_ACER_T17AA_AL1716W
Y0A1 7730203572P0A CD_MANUAL_ACER_T17AN_AL1716W
Y0B1 7730203573P0A CARD_QSG_ACER_T17AN_AL1716W_EMEA
Y0C1 7730203132P0D CARD_WARRANTY CARD_ACER_R17AA_AL1717 _ACER_19L
Y0E1 7730203431P0B CARD_OOBE BOOKLET_ACER
Y0F1 7730203451P0A CARD_SP LEAFLET_ACER_ALL MODELS_EMEA
5. Spare Parts List (continued)
