Acer AL1717 - Disassembly Block; Lcd Monitor

Acer Service Manual
10
2. Disassembly Block
Note:
The DIS assembly direction please following direction of arrowhead
ASSY, BASE
BACK COVER
SPEAKER*1
SCREW,,CROSS, T3*8,Zn, *2
Keypad*1
ASSY STAND
M4*6,Black Zn,NL ROHS *4
BRACKET FINGER *1
HINGE *1
STAND
M4*20,Zn ROHS *3
ASSY FRONT BEZEL
LE 1717
LCD Monitor
Chassis*1
SCREW,,CROSS, M3*5,Zn *4
BOLT,#4-40x11.8,Ni ROHS *2(DVI)
BOLT,#4-40x11.8,Ni ROHS *2(VGA)
PANEL INNOLUX
PCBA I/F BOARD *1
PCBA INV.&DC-DC *1
HRN ASS'Y 8P
CABLE 30 PIN FFC
SCREW,,CROSS,M3*6,Zn *4
SCREW,P,CROSS W/W-SPR,M3*6,Zn*1
FRONT BEZEL *1
FUNCTION KEY *1
POWER BUTTON *1
LED LENS
HINGE COVER*1
BASE*1
RUBBER FOOT *4
GASKET*1
PLATE,BASE*1
SCREW,,CROSS,T4*6,Zn, *1
Assy Panel*1
