Acer AL2017 - Assembly Block

Acer Service Manual
5. LE2018 DIS-assembly Block
12
Note:
The DIS assembly direction please following direction of arrowhead
ASSY PANEL UNIT
CHASSIS *1
PCBA I/F BOARD *1
PCBA INV.&DC-DC *1
CABLE KEYPAD*1
CABLE 30P FFC
BOLT,#4-40x11.8,Ni ROHS *4
M3*5,Ni ROHS *5
TAPE ACE *3
M3*6,W/W-SPR Zn ROHS*1
Gasket,W8*H3*L50*1
Foil,AL,L60*W35*1
ASSY, BASE
BASE*1
RUBBER FOOT *4
GASKET*1
PLATE,BASE*1
T4*6,Zn, ROHS *2
BACK COVER
ASSY STAND
M4*8,Black Zn,NL ROHS *4
SCREW,B,CROSS,T.T-4*8,BLK
ROHS*2
BRACKET FINGER *1
HINGE *1
STAND
SCREW,B,CROSS,W/W-SPR,M4*20,Zn ROHS *3
ASSY FRONT BEZEL
LE 2018
LCD Monitor
FRONT BEZEL *1
FUNCTION KEY *1
POWER BUTTON *1
LED LENS
HINGE COVER*1
SPEAKER*1
PANEL CMO M201P1-L01
