Acer Service Manual
28
Attachment 1- Bill of Material
PCBA IF
ITEM P/N Description Location
790771300000R PCBA,I/F BOARD,W/SPK,LE1753-012 ROHS
10 629030009100R PROGRAM,W/SPK,LE1753-012 ROHS
20 790771340600R PCBA,I/F BOARD,SMD,LE1753-612
30 790771320600R PCBA,I/F BOARD,OTHERS,LE1753-612
40 511130001200R SOLDER BAR,Sn96.5/Ag3.0/Cu0.5/Ni0.06/Ge0
790771320600R PCBA,I/F BOARD,OTHERS,LE1753-612
10 440819015030R CON,D-SUB,FEM.15P RA W/O SCREW DZ11AA1-H CN101,
20 443842024060R CON,DVI-D RA 24+1P FEM.W/O SCR EW,QH1112 CN102,
30 430631080070R WFR 2.0mm 8P 180°4500-08 RoHS CN103,
40 430631080130R WAFER 2x4P 2.0mm,200PHD-2*4ST RoHS CN104,
50 420271010460R CAP SE 100uF 16V M,105 ST,6.3*11 ROHS℃ C130,
60 420274790560R CAP SE 4.7uF 50V M,105 ST,5X11 ROHS℃ C132,
70 420432200460R CAP EC 22uF 16V M,105 ST, 5x11,RoHS℃ C144,
80 432008010270R XTAL 14.31818MHz HC-49US DIP 16pF 30PPM X101,
90 420431010460R CAP EC 100uF 16V M,105 ST 5x11,RoHS℃ C135, C152, C138,
790771340600R PCBA,I/F BOARD,SMD,LE1753-612
10 444099030030R CON, SMD 1.0mm 30PIN RoHS AL2309-A0G1Z CN106,
20 419301010560R C SMD(0603) NPO 100PF/50V J RoHS C163,C164,C165,C166,C167,
30 419351044010R C SMD(0402) X5R 0.1uF/16V K,RoHS
C139,C140,C141,C142,C145,C1
46,C147,C148,C149,C153,C154,
C155,C156,C157,
40 419311040060R C SMD(0603) X7R 0.1uF/50V K RoHS
C117,C120,C121,C131,C133,C1
34,C136,C143,C151,C161,C162,
C168,
50 419341054670R C SMD(0805) Y5V 1uF/16V Z RoHS REV:A C160,C137,
60 419301000560R C SMD(0603) NPO 10PF/50V J RoHS C158,C159,
70 419302210560R C SMD(0603) NPO 220PF/50V J RoHS C116,
80 419303300560R C SMD(0603) NPO 33PF/50V J RoHS C115,
90 419314734010R C SMD(0402) X7R 0.047uF/16V K,RoHS
C101,C102,C103,C106,C108,C1
10,
110 414918010050R RES SMD (0402) 10Ω J,RT,RoHS
R130,R131,R132,R133,R134,R1
35,R137,R138,
120 414918560910R RES SMD (0402) 56Ω F,RT,RoHS R101,R102,R103,
130 414916010150R RES SMD (0603) 100Ω J,RT RoHS REV:A R185,R186,
140 414916010250R RES SMD (0603) 1KΩ J,RT RoHS REV:A
R113,R115,R116,R125,R143,R1
55,R156,R167,R168,R175,R177,
150 414916010350R RES SMD (0603) 10KΩ J,RT RoHS
R111,R123,R124,R136,R141,R1
52,R153,R157,R158,R160,R161,
R162,R163,R164,R172,R173,R1
74,R178,R179,R180,R181,R182,
R183,R184,R119,R120,R128,
R129,
160 414916010450R RES SMD (0603) 100KΩ J,RT REV:A RoHS R147,
190 414916047350R RES SMD (0603) 47KΩ J,RT RoHS R150,
200 414916022250R RES SMD (0603) 2.2KΩ J,RT RoHS R118,R117,
210 414918390010R RES SMD (0402) 390Ω F,RT,RoHS R154,
220 414916047050R RES SMD (0603) 47Ω J,RT RoHS R121,R122,R126,R127,
230 414916047250R RES SMD (0603) 4.7KΩ J,RT RoHS R139,R142,R149,R176,
240 414916022050R RES SMD (0603) 22Ω J,RT RoHS R146,
250 414916750910R RES SMD (0603) 75Ω F,RT RoHS REV:A R105,R106,R107,
