Chapter 1 11
Hardware Specifications and Configurations
Processor
Throttling 50%: On= 99 C; OFF=93 C
OS shut down at 105 C; H/W shot down at 110 .C
Item Specification
CPU type
Intel
®
Corei3 i3-2310M PGA 2.1G 35W
Intel
®
Core i5 2410M PGA 2.3G 35W
Intel
®
Core i5 2520M PGA 2.5G 35W
Intel
®
Core i5 2540M PGA 2.6G 35W
Intel
®
Core i7-2620M PGA 2.7G 35W
Intel
®
Core i7-2630QM PGA 2.0G 45W
Intel
®
Core i7-2720QM PGA 2.2G 45W
Intel
®
Core i7-2820QM PGA 2.3G 45W
Core logic PCH/HM65 Express chipset
CPU package PGA 988
CPU Fan True Value Table
DTS(degree C) Fan Speed (rpm) Acoustic Level (dBA)
45-50 0-3000 29
55-66 0-3300 33
68-74 3300-3800 38
78-83 3800-4100 40
86-91 4100-4800 40
BIOS
Item Specification
BIOS vendor Phoenix
BIOS Version 1.0
Supported protocol ACPI 1.0b/2.0/3.0 compliance, PCI 2.2, System/HDD Password
Security Control, INT 13H Extenstions, PnP BIOS 1.0a SMBIOS
2.4, BIOS Boot Specification, Simple Boot Flag 1.0, Boot Block,
PCI Bus Power Management Interface Specification, USB
Specification 1.1/2.0, IEEE 1394 1.0, USB/1394 CD-ROM Boot Up
support, PC Card Standard 1995 (PCMCIA 3.0 Compliant Device),
IrDA 1.0, Intel AC97 CNR Specification, WfM 2.0, PXE 2.1, Boot
Integrity Service Application Program Interface (BIS) 1.0, PC99a
and Mobile PC2001 Compliant
System Memory
Item Specification
Memory controller Built-in
Memory size 0MB (no on-board memory)
DIMM socket number 2 sockets
Supports memory size per socket 2048MB
Supports maximum memory size 4G for 64bit OS (with two 2GB SODIMM)
Supports DIMM type DDR 3 synchronous DRAM
