Acer Aspire 4350 User Manual

Chapter 3 43
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
Item Screw Color Part No.
A M2.5 x L6 Black 86.00E12.536
C M2 x L3 Black 86.00F80.723
MAIN UNIT
KEYBOARD
MAIN UNIT DISASSEMBLY
CPU
SCREW X 5
RTC
BATTERY
Ax 10
UPPER CASE
C x 3
Ax 2
SPEAKER
MODULE
C x 4
TOUCHPAD
MODULE
POWER
BUTTON
BOARD
C x 1
USB
BOARD
BLUETOOTH
MODULE
MAIN
BOARD
Ax1
HEATSINK
MODULE
LCD MODULE
Ax4
