Aspire 6930/6930G Series
Service Guide
PRINTED IN TAIWAN
Service guide files and updates are available
on the ACER/CSD web; for more information,
please refer to http://csd.acer.com.tw

Table of Contents

Questions and Answers

  • J
    James FuentesAug 13, 2025
    How to fix Acer Aspire 6930G when it won't power on?
    • X
      xmorrowAug 13, 2025
      If your Acer Laptop isn't powering on, ensure the power cable is securely connected to both the laptop and the electrical outlet. Try removing any extension cables or surge protectors, plugging the laptop directly into a known good outlet. Disconnect the power and open the casing to check the Thermal Unit and fan airways are free of obstructions. Also, remove any external and non-essential hardware and recently installed software that are not necessary to boot the computer to the failure point.
  • J
    James GillespieAug 17, 2025
    What to do if my Acer Aspire 6930G has no display?
    • G
      Gary PetersAug 17, 2025
      If your Acer Laptop screen is blank, first, ensure the internal display is selected by pressing Fn+F5. Check that the laptop has power—fans should start, or status LEDs should light up. You can also try these steps: * Remove the power cable and battery, then hold the power button for 10 seconds to drain any stored power. * Reconnect the power and reboot. * Connect an external monitor and switch displays using Fn+F5. * Disconnect all external devices, memory cards, and CD/DVDs before restarting. * Reseat the memory modules and remove the drives.
  • M
    Megan WilsonAug 20, 2025
    How to troubleshoot sound problems on Acer Aspire 6930G Laptop?
    • R
      Renee CunninghamAug 21, 2025
      To troubleshoot sound problems on your Acer Laptop, start by rebooting the computer. Then, go to Start: Control Panel, System and Maintenance, System, Device Manager to check if the audio device is properly installed. If you recently updated the audio driver, roll it back to the previous version. You can also remove and reinstall the audio driver. Make sure all volume controls are set to mid-range. Navigate to Start: Control Panel, Hardware and Sound, Sound, and ensure Speakers are selected as the default audio device (green check mark). Select Speakers and click Configure to start Speaker Setup, following the onscreen prompts. Remove and reinstall any recently installed hardware or software. As a last resort, restore system and file settings from a known good date using System Restore.
  • J
    jameskingAug 25, 2025
    Why is my Acer Aspire 6930G video display abnormal?
    • N
      Nathan LeachAug 25, 2025
      If your Acer Laptop's video display is abnormal, start by rebooting the computer and adjusting the brightness to its highest level. Also, check that the display resolution is correctly configured. If permanent vertical/horizontal lines or dark spots are present, or if there's extensive pixel damage (different colored spots in the same locations), or if the display is too dim even at the highest brightness, the LCD is faulty and should be replaced.
  • J
    Julie WatsonAug 28, 2025
    How to fix internal microphone failure on Acer Aspire 6930G?
    • A
      Andrew BaileyAug 28, 2025
      To resolve internal microphone failure on your Acer Laptop, first check that the microphone is enabled by navigating to Start: Control Panel: Hardware and Sound: Sound and selecting the Recording tab. Right-click in the Recording tab and select 'Show Disabled Devices'. Then, right-click on the microphone and select 'Enable'. Select the microphone, click 'Properties', and go to the 'Levels' tab to increase the volume to the maximum setting. Finally, test the microphone hardware by selecting the microphone and clicking 'Configure'.
  • U
    ugarciaSep 1, 2025
    What to do if HDD is not operating correctly on Acer Aspire 6930G Laptop?
    • D
      dalemorseSep 1, 2025
      If the HDD in your Acer Laptop isn't operating correctly, begin by disconnecting all external devices. Run a complete virus scan using up-to-date software. You can also run the Windows Vista Startup Repair Utility. Restart the computer and press F2 to enter the BIOS Utility to check the BIOS settings. Ensure all cables and jumpers on the HDD and ODD are set correctly. Remove any recently added hardware and associated software.
  • R
    rphamSep 4, 2025
    Why is my external mouse failing on my Acer Laptop?
    • C
      Chad VillanuevaSep 4, 2025
      If you're experiencing external mouse failure with your Acer Laptop, try these steps: Use an alternative mouse. If it's wireless, replace the batteries and ensure a stable connection. For USB mice, try a different USB port. Test the mouse with another program; if it fails, reinstall the program. Restart the computer. Remove any recently added hardware or software and reboot. Restore system settings using System Restore. Check the Event Viewer for errors. If recently updated, roll back or reinstall the mouse driver.
  • D
    Deborah BarrettSep 8, 2025
    Why does my Acer Aspire 6930G Laptop randomly lose BIOS settings?
    • J
      James MartinSep 8, 2025
      If your Acer Laptop is randomly losing BIOS settings, and the computer is more than one year old, replace the CMOS battery. Run a complete virus scan using up-to-date software. If you're experiencing HDD or ODD BIOS information loss, disconnect and reconnect the power and data cables between the devices. If HDD information is missing from the BIOS, the drive may be defective and should be replaced. As a last resort, replace the Motherboard.

Summary

Chapter 1: System Specifications

Features

Lists key computer features, noting those specific to certain models.

Platform

Details processor technology, chipsets, and wireless modules.

System Memory

Specifies SDRAM support, capacity, speed, and module type.

Display and graphics

Information on screen resolution, aspect ratio, and graphics chipsets.

I;O interface

Details external connectivity ports like USB, HDMI, Ethernet.

Hardware Specifications and Configurations

Technical details for processor, Northbridge, Southbridge, and system chips.

Chapter 2: System Utilities

BIOS Setup Utility

Tool for configuring system hardware and boot options.

BIOS Flash Utility

Procedure for updating the system's BIOS firmware.

Remove HDD;BIOS Utility

Steps to reset or clear HDD and BIOS passwords.

Chapter 3: Machine Disassembly and Replacement

Disassembly Requirements

Lists necessary tools and notes for disassembling the computer.

External Module Disassembly Process

Flowchart and steps for removing external laptop components.

Main Unit Disassembly Process

Step-by-step guide for disassembling internal laptop components.

LCD Module Disassembly Process

Instructions for taking apart the laptop's LCD assembly.

LCD Module Reassembly Procedure

Steps for putting the laptop's LCD module back together.

Chapter 4: Troubleshooting

Common Problems

A guide to diagnose issues by mapping symptoms to relevant pages.

Power On Issue

Troubleshooting steps for power-related problems.

No Display Issue

Steps to resolve problems with the computer screen not displaying video.

LCD Failure

Specific troubleshooting guide for LCD screen malfunctions.

HDD Not Operating Correctly

Procedures to fix issues with the hard disk drive not functioning.

POST Codes Tables

Reference for POST codes, drivers, and keys used during system startup.

Chapter 5: Jumper and Connector Locations

Top View

Diagram illustrating jumper and connector positions on the motherboard's top side.

Bottom View

Diagram illustrating jumper and connector positions on the motherboard's bottom side.

Clearing Password Check and BIOS Recovery

Procedures for clearing BIOS passwords and performing BIOS recovery.

Chapter 6: FRU (Field Replaceable Unit) List

Aspire 6930;6930 G Exploded Diagrams

Visual breakdown of laptop components with corresponding part numbers.

Aspire 6930;6930 G FRU List

Detailed list of all replaceable units and their Acer part numbers.

Appendix A: Model Definition and Configuration

Aspire 6930;6930 G Series

Table listing model variants, country, and CPU configurations.

Appendix B: Test Compatible Components

Microsoft Windows Vista Environment Test

List of components tested for compatibility with Windows Vista.

Peripheral Tests

List of tested external devices and peripherals for system compatibility.

Appendix C: Online Support Information

Technical Information Downloads

Information on downloading service guides, manuals, and BIOS updates from Acer.

Acer Aspire 6930G Series Specifications

General IconGeneral
ProcessorIntel Core 2 Duo
GraphicsNVIDIA GeForce 9600M GT
RAMUp to 4GB DDR2
Battery6-cell Li-ion
Weight3.5 kg
Display16-inch, 1366x768 resolution
Storage320GB HDD
Optical DriveDVD-Super Multi
Operating SystemWindows Vista
ChipsetIntel PM45
Wireless802.11a/b/g/n
