Your Acer notebook tour - 11
Left view
1 2 3 4 5 6 7
3 Touchpad
Touch-sensitive pointing device
which functions like a computer
mouse.
4
Click buttons
(left and right)
The left and right side of the button
function as left and right selection
buttons.
# Icon Item Description
1
Kensington lock
slot
Connects to a Kensington-
compatible computer security lock.
Wrap the computer security lock
cable around an immovable object
such as a table or handle of a locked
drawer.
Insert the lock into the notch and turn
the key to secure the lock.
Keyless models are also available.
2 Ventilation
Allows the computer to stay cool.
Do not cover or obstruct the
openings.
3
External display
(VGA) port
Connects to a display device (e.g.,
external monitor, LCD projector).
4
Ethernet (RJ-45)
port
Connects to an Ethernet 10/100/
1000-based network.
5
HDMI port
Supports high-definition digital video
connections.
6
USB port Connects to USB devices.
# Icon Item Description
