Acer Aspire M5630 - Veriton Rear Panel; VeritonM460;S460 Rear Panel

15
VeritonM460/S460 Rear Panel
Label Description Label Description
1 Power card socket 8 Monitor connector
2 Voltage selector switch 9 USB 2.0 ports
3 Fan aperture 10 RJ-45 Ethernet connector
4 PS/2 keyboard connector 11 Microphone jack
5 PS/2 mouse connector 12 Line-out jack
6 Serial port 13 Line-in jack
7 Printer connector 14 Extension card slots
