Acer Aspire One ZA3 - Notebook Rear and Base Features; Battery and Storage Features; Connectivity and Cooling Features

Quick Guide
11
Rear & Base view
# Icon Item Description
12
Batterybay Houses the computer's battery pack.
Note: The battery shown is for reference
only. Your PC may have a different battery,
depending on the model purchased.
13
3G SIM card slot Accepts a 3G SIM card for 3G connectivity.
Note: Insert a 3G SIM card to enable 3G
communication. The SIM card connectors
need to face away from the cover.
(Only for certain models)
14
Batterylock Locks the battery in position.
15
Hard disk bay Houses the computer's hard disk (secured
with screws).
16
WirelessLANBay Houses the computer's Wireless LAN
module.
17
Ventilation slots and/
or cooling fan
Enables the computer to stay cool, even
after prolonged use.
Note: Do not cover or obstruct the opening
of the fan.
18
Memory
compartment
Houses the computer's main memory.
19
Batteryreleaselatch Releases the battery for removal.
