57 Chapter 6
Aspire R3610 Exploded Diagram
NOTE: This section will be updated when more information becomes available.
NO PART NO QTY NO PART NO QTY
1 Bot-cover 1 8 01-Main-base 1
2 Cover-pannel 1 9 POWER-BUTTON 1
3 SHEETMETAL-TOP 1 10 2009_Acer 1
4 ACER-1L-MB-LOYOUT 1 11 Top-Cover 1
5 ANTENNA_P_7 1 12 ANTENNA_B_8 1
6 1L-Power-Switch 1 13 V-STAND 1
7 SHEETMETAL-BOT 1
