Disassembly Procedures 1-23
LCD Panel Removal 0
Prerequisite:
LCD Bezel Removal
1. Locate the LCD panel (C) on the LCD cover. Refer to Figure 1-31.
2. Remove four (4) screws (A) securing the LCD panel in place (Figure 1-31).
Figure 1-31. LCD Panel Removal
3. Carefully flip the LCD panel over so that the LCD panel faces down and is placed on a
flat surface as shown in Figure 1-32.
4. Peel back the piece of adhesive tape securing the eDP cable to the LCD panel
connector (D) (Figure 1-32).
Figure 1-32. LCD Panel Removal
A
A
C
WEEE Annex VII Component: LCD Panel
To Next Page
