Acer Chromebook C738T User Manual

1-22 Disassembly Procedures
5. Pull the eDP cable (A) out of the left hinge cap to remove the left hinge cap stopper
(B) (Figure 1-28).
Figure 1-28. LCD Module Left Hinge Cap Stopper
6. Pull the WLAN antennas (C) out of the right hinge cap to remove the right hinge cap
stopper (D) (Figure 1-29).
Figure 1-29. LCD Module Right Hinge Cap Stopper
B
A
D
C

Acer Chromebook C738T Specifications

General

Processor	Intel Celeron N3150
RAM	4GB
Storage	16GB eMMC
Display	11.6-inch
Resolution	1366 x 768
Operating System	Chrome OS
Touchscreen	Yes
Graphics	Intel HD Graphics
Wireless	802.11ac Wi-Fi, Bluetooth 4.0
Processor Speed	1.6 GHz
Ports	1 x HDMI
