Disassembly Procedures 1-21
10. Release the I/O bracket from the USB port slot and guide pins (I) on the top assembly.
Then remove the I/O bracket (J) (Figure 1-27).
Figure 1-27. Mainboard Removal
11. Release the mainboard from the I/O ports slots and guide pins (K) on the top
assembly. Then remove the mainboard (L) (Figure 1-28).
Figure 1-28. Mainboard Removal
J
I
I
WEEE Annex VII Component:
Mainboard
K
K
L
