1-20 Disassembly Procedures
4. Remove one (1) screw securing the USB board in place (Figure 1-24).
Figure 1-24. USB Board Removal
5. Remove the USB board from the top assembly (Figure 1-25).
Figure 1-25. USB Board Removal
D
B
E
F
G
C
WEEE Annex VII Component:
USB Board
