Acer Chromebook Spin R752T - WLAN Module Removal

Disassembly Procedures 1-9
WLAN (Wireless Local Area Network) Module Removal 0
Prerequisite:
Battery Pack Removal
1. Locate the WLAN module (B) on the top assembly (Figure 1-9).
Figure 1-9. Component Location
2. Disconnect WLAN antennas cables (J) from the WLAN module connectors
(Figure 1-10).
3. Remove one (1) screw (K) securing the WLAN module in place (Figure 1-10).
Figure 1-10. WLAN Module Removal
F
B
C
G
H
D
E
K
J
