Acer Chromebook Spin R752T User Manual

1-8 Disassembly Procedures
Battery Pack Removal 0
Prerequisite:
Base Cover Removal
1. Locate the battery (B) on the top assembly (Figure 1-7).
2. Disconnect the battery cable (C) from the mainboard connector (D) (Figure 1-7).
Figure 1-7. Battery Pack Removal
3. Remove the battery pack from the system (Figure 1-8).
Figure 1-8. Battery Pack Removal
IMPORTANT:
+
Follow local regulations for battery disposal.
D
C
B
WEEE Annex VII Component: Battery Pack

Acer Chromebook Spin R752T Specifications

General

RAM	4GB LPDDR4
Storage	32GB eMMC
Resolution	1366 x 768
Operating System	Chrome OS
Battery Life	Up to 10 hours
Graphics	Intel UHD Graphics 600
Wireless	802.11ac Wi-Fi
Bluetooth	Bluetooth 5.0
Display	11.6-inch IPS touchscreen
Dimensions	11.65 x 8.11 x 0.79 inches
Ports	2 x USB-C, 2 x USB 3.0, MicroSD card reader, Audio combo jack
