Acer Chromebook Spin R752T - Page 9

Disassembly Procedures 1-7
3. Work your way around the left, right and bottom sides of the base cover (Figure 1-5).
Figure 1-5. Base Cover Removal
4. Slide the base cover in the indicated direction and remove the base cover from the
system (Figure 1-6).
Figure 1-6. Base Cover Removal
