Acer Dynamic 1722S - Page 45

45
HEADSTOCK ASSMBLY (Spindle Bore
：
78mm or 3")
Item
No.
Part Name QTY
Model:17" (430)
Part No.
Model:19"
(480)
Part No.
Model:21"
(530)
Part No.
1 Head stock 1 3001001-173 3001001-193 3001001-213
2 Oil plug 1 1122103405 1122103405 1122103405
3 Head stock cover 1 1120200509 1120200509 1120200509
4 Blanket 1 1003501701 1003501701 1003501701
5
Hexagon socket screw
，
M6xP1x35L
4
6
Hexagon socket screw
，
M8xP1.25x25L
1
7
Snap ring
，
R48
1
9 Input-shaft 1 1120200607 1120200607 1120200607
10
Ball bearing
，
6206
1 91301021 91301021 91301021
11 Gear-i 1 20200705B 20200706B 20200706B
12 Gear-g 1 1120200803 1120200803 1120200803
13
Square key
，
8x7x55L
1
14
Ball bearing
，
6206
2 91301021 91301021 91301021
15 Collar 1 3001015-001 3001015-001 3001015-001
17 Housing 1 1120206903 1120206903 1120206903
18
Oil-seal
，
TC30x50x8
1
19
Hexagon socket screw
，
M6xP1x35L
4
20 Pulley 1 3001020 3001020 3001020
21
Square key
，
8x7x45L
3
22
Hexagon socket screw
，
M8xP1.25x25L
1
23
Spring washer
，
12
1
24 Shaft-B 1 1120202503 1120202503 1120202503
25 Gear-d 1 1120200901 1120200901 1120200901
26 Gear-b 1 1120201006 1120201006 1120201006
27 Gear-f 1 1120201104 1120201104 1120201104
28 Gear-k 1 1120201202 1120201202 1120201202
29 Gear-o 1 122020110 122020110 122020110
30 Plug-cover 2 1120202905 1120202905 1120202905
