Acer Dynamic 1722S - Page 46

46
HEADSTOCK ASSMBLY (Spindle Bore
：
78mm or 3")
31
O-ring
，
P55x3.5
2
32 Fixed pin 2 1120206707 1120206707 1120206707
33 Set screw 2 1120206805 1120206805 1120206805
34 Shaft-A 1 1120202601 1120202601 1120202601
34-1 Shaft-L 1 1120202709 1120202709 1120202709
35
Ball-bearing
，
6305
2 91301029 91301029 91301029
36 Gear-I 1 1120201408 1120201408 1120201408
37 Gear-M 1 122020120 122020120 122020120
38
Snap ring
，
S65
2
39
Snap ring
，
S30
1
40
Ball bearing
，
6005
3 91301010 91301010 91301010
41 Gear-E 1 1120201506 1120201506 1120201506
42 Gear-A 1 1320200307 1320200307 1320200307
43 Gear-C 1 1320200405 1320200405 1320200405
44
Square key
，
8x7x35L
1
45
Snap ring
，
S48
2
46
Snap ring
，
S34
1
47 Gear-h 1 1120201604 1120201604 1120201604
48 Gear-j 1 320200503B 320200503B 320200503B
49
Square key
，
8x7x25L
1
50
Ball bearing
，
6205
2 91301020 91301020 91301020
51 Cover 1 1120203108 1120203108 1120203108
52 Spindle (D1-8) 1 122020090 122020090 122020090
53
Taper roller bearing
，
32922
1 91302028 91302028 91302028
54 Cover 1 3001054-003 3001054-003 3001054-003
55
Hexagon socket screw
，
M6xP1.0x35L
6
56 Gear-p 1 122020130 122020130 122020130
57 Gear-n 1 122020140 122020140 122020140
58
Square key
，
8x7x85L
1
59 Lock-nut 1 3001059-001 3001059-001 3001059-001
60
Set screw
，
M8x1.25x8L
5 91120808 91120808 91120808
61
Taper roller bearing
，
32920
1 91302029 91302029 91302029
62 Lock-nut 1 3001062-001 3001062-001 3001062-001
