57
APRON ASSEMBLY
ITEM
NO.
Part Name
QTY
Model: 17"
(430)
Part No.
Model: 19"
(480)
Part No.
Model: 21"
(530)
Part No.
1
Body-Apron (right hand) 1 1210900209 1210900209 1210900209
(left hand)
1
1210900101
1210900101
1210900101
2 Gib 1 1210901706 1210901706 1210901706
3
Hexagon socket screw ,
M6xP1.0x16L
17
4
Holder-half nut (right hand) 1 1210900405 1210900405 1210900405
(left hand)
1
1210900307
1210900307
1210900307
5
Nut-half (in) 1 121090051 121090051 121090051
(mm) 1 121090061 121090061 121090061
6
Nut-half (in) 1 121090051 121090051 121090051
(mm) 1 121090061 121090061 121090061
7
Holder-half nut (right hand) 1 1210900405 1210900405 1210900405
(left hand)
1
1210900307
1210900307
1210900307
8
Hexagon socket screw ,
M6xP1.0x16L
1
9 Pin-sliding 2 1210902507 1210902507 1210902507
10 Shaft-haft nut (right hand) 1 1210900807 1210900807 1210900807
(left hand)
1
1210900709
1210900709
1210900709
11 Ring-O , P26 2
12 Set screw , M8xP1.25x20L 2 1210902605 1210902605 1210902605
13 Hub (right hand) 1 121090141 121090141 121090141
(left hand) 1 1210901304 1210901304 1210901304
14 Ball-steel , 1/4" 3
15 Spring , φ1x6x30L 3
16 Set screw , M8xP1.25x10L 2
17 Lever 2 1210902703 1210902703 1210902703
18 Knob 2 1120207400 1120207400 1120207400
19 Screw , 4x10 4
APRON ASSEMBLY
