58
20 Lenx-oil, CTA-8 1 1210902801 1210902801 1210902801
21 Shaft-auto stop 1 1210902909 1210902909 1210902909
22 Cover-bottom apron 1 1210903004 1210903004 1210903004
23 Seal-oil , 15x25x7 1
24 Seat-tappet 1 1121601804 1121601804 1121601804
25 Shaft-tappet 1 1121601902 1121601902 1121601902
26 Set screw , M6xP1.0x16L 2
27 Tappet 1 1121602007 1121602007 1121602007
28 Nut , M8xP1.25 1
29 Set screw , M8xP1.25x30L 1
30 Set screw , M6xP1.0x40L 1
31 Set screw , M6x40 1
32 Nut , M6xP1.0 2
33 Screw-oil leakage , PT1/4 1 92590601 92590601 92590601
34 Seal-oil , 32x42x10 1
35 Bushing 2 1210901804 1210901804 1210901804
36 Sleeve-feed rod 1 1210901902 1210901902 1210901902
37 Key-sqaure , 6x6x42L 1
38 Key-sqaure , 6x6x12L 1
39 Gear 1 1210903200 1210903200 1210903200
40 Seat-worm 1 1210903308 1210903308 1210903308
41 Shaft-worm 1 1210903406 1210903406 1210903406
42 Bearing-thrust , 2904 2 91311005 91311005 91311005
43 Worm gear 1 1210902007 1210902007 1210902007
44 Washer-lock , 20 1
45 Nut 1
46
Hexagon socket screw ,
M6xP1.0x30L
1
47 Spring , φ1x10x60L (right) 1 1210905400 1210905400 1210905400
(left)
1
1210905508
1210905508
1210905508
48 Block-safe device (right) 1 1210901000 1210901000 1210901000
(left)
1
1210900905
1210900905
1210900905
49 Pin , 5x18L 2
50 Pin 1
APRON ASSEMBLY
