Acer Dynamic 1722S - Page 60

60
APRON ASSEMBLY
82 Knob 1 1120207400 1120207400 1120207400
83
Set screw ,
M4xP0.7x10L
1
84 Pinion rack 1 1210904707 1210904707 1210904707
85 Key-square , 6x6x20L 1
86
Bearing needle ,
NK20/22
1 91311001 91311001 91311001
87 Set screw , M8x10 1
88 Collar 1 1210904805 1210904805 1210904805
89 Pin-spring , 6x36L 1
90 Gear 1 1210904903 1210904903 1210904903
91 Bearing-ball , 6003 1 91301005 91301005 91301005
92 Cover 1 1210905008 1210905008 1210905008
93 Pinion-handwheel 1210905106 1210905106 1210905106
94 Key-square , 6x6x25L 1
95 Bearing-ball , 6004V 1 91301008 91301008 91301008
95-1 Bearing-ball , 6005Z 1 91301007 91301007 91301007
96 Seat 1210905204 1210905204 1210905204
97
Hexagon socket screw ,
M6xP1.0x30L
4
99 Washer 1210701608 1210701608 1210701608
100 Washer-wave type 1
101 Dial-rack 1 1220900202 1220900202 1220900202
102 Handwheel 1 112210171 112210171 112210171
103 Handle 1 1121102002 1121102002 1121102002
104 Washer-lock 1 1122101901 1122101901 1122101901
105
Hexagon socket screw ,
M8xP1.25x20L
1
106
Dial-thread chasing
(in 4 parts)
1 1003514708 1003514708 1003514708
(mm 5 parts) 1 1003502404 1003502404 1003502404
(mm 7 parts) 1 1003514904 1003514904 1003514904
107 Pin 1
108 Seat-dial shaft 1 1003514502 1003514502 1003514502
109
Hexagon socket screw ,
M10xP1.5x65L
1
