APRON ASSEMBLY
110 Gear (in 16T) 1 1003514600 1003514600 1003514600
(mm 11T) 1 1003502502 1003502502 1003502502
(mm 13T) 1 1003502600 1003502600 1003502600
(mm 14T) 1 1003514806 1003514806 1003514806
(mm 15T) 1 1003502708 1003502708 1003502708
(mm 18T) 1 1003502806 1003502806 1003502806
111 Washer-spring , 10 1
112 Nut , M10xP1.5 1
113 Snap ring , S30 1
114 Seat-switch 1 1210701706 1210701706 1210701706
115 Key-square , 6x8x25L 1
116
Hexagon socket screw ,
M8xP1.25x16L
2
117 Bracket 1 1210701804 1210701804 1210701804
118 Screw-lock 2 1210701902 1210701902 1210701902
119 Screw-hexa. socket headless cap 1 1210702007 1210702007 1210702007
120 Seat-lever 1 1210702105 1210702105 1210702105
121 Set screw , M8xP1.25x8L 2
122 Spring 1
123 Lever 1 1210702203 1210702203 1210702203
124 Knob 1 1122103601 1122103601 1122103601
