67
BRAKE SYSTEM
24 Belt-brake (5HP , 15HP) 1 1003519605 1003519605 1003519605
(7.5HP , 10HP) 1 1003519703 1003519703 1003519703
25 Belt pulley (5HP/60HZ) 1 3005025 3005025 3005025
(7.5HP
、
10HP/60HZ)
1 3005025-004 3005025-004 3005025-004
26 Set screw , M8xP1.25x8L 1
27 Key , 8x7.5x40 (5HP) 1
10x8x65 (7.5HP) 1
(10HP) 1
12x8x80 (15HP) 1
28 Motor (5HP/220/440/60) 1 81000103 81000103 81000103
(7.5HP/220/440/60) 1 81000205 81000205 81000205
29 Bolt-hexa. head , M10x30L 4
