English
SPECIFICATIONS
LCD Panel
Driving system TFT Color LCD
Size 31.5"W(80cm)
Pixel pitch 0.2727(H) x 0.2727(V) mm
Brightness (cd/m
2
) 300 (Min/Typ)
Contrast 100,000,000:1 Max (ACM)
Viewable angle CR=10, 178°(H), 178°(V)
Response time 4ms (G to G)
Panel Type In-Plane Switching
Video R, G, B Analog Interface
H-Frequency 30KHz-100KHz
V-Frequency 50Hz-75Hz
Display Colors 1.07B(8bit+FRC)
Dot Clock 241.6 MHz
Max. Resolution 2560 x 1440@60Hz
Plug & Play VESA DDCCI/DDC2B
Energy Efficiency Class A
*Annual Energy Consumption 56 (kWh) (for HDMI-input Model)
Power consumption
(at 300 nits)
On Mode 46W(typical)
Sleep Mode 0.4W(typical)
Off Mode 0.37W(typical)
Input Connector
DP (Only DP-Input Model)
HDMI (Only HDMI Model)
DVI-DL 24pin (Only Dual-Input Model)
Input Video Signal
Digital signal (Only Dual-Input Model)
DP signal (Only DP Model)
HDMI signal (Only HDMI Model)
Maximum Screen Size
Horizontal 698.112mm
Vertical 392.688mm
Power Source 100-240V~, 50/60Hz
Environmental Considerations
Operating Temp: 0° to 40°C
Storage Temp: -20° to 60°C
Operating Humidity: 20% to 80%
Dimensions (W x H x D) 725.9 x 479 x 180mm
Weight (N. W.) 6.4kg (net)
Mechanism specifications
Tilt: - 5° to +10°
Swivel: No
Height adjustment: No
Pivot: No
Detachable foot stand: Yes
External Controls
Buttons
Power Button
Page Left /Right/Exit
Menu/Enter
PIP / Input
E(Empowering) Key/ Volume
Functions
Acer eColor Management
BlueLight
Brightness
Contrast
Colour Temp
sRGB mode
Gmma
Super Sharpness
6-axis Hue
6-axis Saturate
Language
OSD Timeout
Wide Mode
DDC/CI On/Off
ACM On/Off
Input
OD
Quick Start Mode
PIP/PBP
Reset
Information
*All specifications are subject to change without notice.
