Acer EB321HQ User Manual

10
Power Switch / Power LED:
To turn the monitor ON or OFF.
Lights up to indicate the power is turned ON.
Using the Shortcut Menu
Press the function button to open the shortcut menu. The shortcut menu lets you quickly
select the most commonly accessed settings.
empowering
Press the Empowering Key to open the Acer eColor Management OSD and accessthe
scenario modes.
PIP Picture in picture hotkey
Press this button to active the picture-in-picture function.
MENU OSD functions
Press this botton to activate the OSD menu.
Volume Up / Down
Press to adjust volume (Only Earphone Mode).
INPUT Input Key
Use Input key to select from dierent video sources that may be connected to your
monitor.
(a) DP input (b) HDMI input (b) DVI-DL input
As you cycle through the sources you will see the following messages on right top side
of screen to indicate currently selected input source. It may take 1 or 2 seconds for the
image to appear.
DP or HDMI or DVI -DL
If either HDMI or DVI-DL input is selected ,but the HDMI and DVI-DL cables are not
connected, a oating dialog box indicates:
“No Cable Connect” or “No Signal”
USER CONTROLS
DCBAPOWER

Acer EB321HQ Specifications

General

3D	No
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	31.5 \
Display technology	LED
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	-
Display number of colors	16.78 million colors
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
No flickering	Yes
Tilt angle range	-5 - 15 °
Cables included	VGA
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Power consumption (standby)	0.45 W
Power consumption (typical)	52 W
Certification	MPR II
Product color	White
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	180 mm
Height (with stand)	486 mm
Weight (with stand)	6894 g
Depth (without stand)	52 mm
Width (without stand)	729.8 mm
Height (without stand)	430 mm
Weight (without stand)	6304 g
