Acer eMachines E730 Series - Front View (Closed); Rear View

7
English
Closed front view
1. The front panel indicators are visible even when the computer cover is closed up.
Rear view
# Icon Item Description
1 Power indicator Indicates the computer's power status.
2
Battery indicator
1
Indicates the computer's battery status.
1. Charging: The light shows amber when
the battery is charging.
2. Fully charged: The light shows blue
when in AC mode.
3 Multi-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory Stick (MS),
Memory Stick PRO (MS PRO), xD-Picture
Card (xD).
Note: Push to remove/install the card. Only
one card can operate at any given time.
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
12 3
1
