Projector Overview
Projector Outlook
Front / upper side
Rear side
# Description # Description
1
Lens cap
5
Remote control receivers
2
Tilt adjusting wheel
6
Control panel
3
Zoom Lens
7
Power button
4
Focus ring
# Description # Description
1 SD Card reader 6 Composite video input connector
2 USB A connector (for multimedia) 7
Audio/Video In (3.5mm Mini Jack, for
audio/ composite source, iphone/ipod
support)
3 Mini USB 8 Audio output connector
4 HDMI connector 9 Power socket
5
PC analog signal/HDTV/component
video input connector
10 Kensington™ lock port
7
6
1
2
3
5
4
5
3
4
9
12
10
5
6
7 8
