5 Adjust the angle and positioning as necessary.
Note: The appropriate type of screw and washer for each model is
listed in the table below. 3 mm diameter screws are enclosed in
the screw pack.
Models Screw Type B Washer Type
Diameter (mm) Length (mm) Large Small
K330/L225/LK-W14 3 25 V V
3
Tightening Screw
Allen Key
Allen Key
Tightening Screw
49 mm
62 mm
61 mm69 mm
41 mm
SCREW SPEC. M3 x 25 mm
