Ports and connectors - 21
• For optimal performance, use USB 3.0-certified devices.
• Defined by the USB 3.0 specification (SuperSpeed USB).
Rear panel audio ports
The table below indicates the functions of the audio jacks on the rear panel (if available).
Icon color Headset Stereo Quadrophonic 5.1-channel
Blue
Rear Rear
Green
Headset Front Front Front
Blue
Mic-in Mic-in Mic-in Center/woofer
