46
English
5 Adjust the angle and positioning as necessary.
Screw Type B Washer Type
Diameter (mm) Length (mm) Large Small
425VV
360°
55.00 mm
55.00 mm
82.30 mm
83.84 mm
SCREW SPEC. M4 x 25 mm
