Acer TMP214-52 - SSD Module Removal

1-14 Disassembly Procedures
SSD Module Removal 0
Prerequisite:
Battery Pack Removal
1. Remove one (1) screw securing the SSD module (A) in place (Figure 1-17).
Figure 1-17. SSD Module Removal
2. Remove the SSD module from the mainboard connector (B) (Figure 1-18).
Figure 1-18. SSD Module Removal
A
B
WEEE Annex VII Component:
SSD Module
