Disassembly Procedures 1-15
LTE Module Removal (LTE SKU Only) 0
Prerequisite:
Battery Pack Removal
1. Find the LTE module (A) on the top assembly (Figure 1-19).
2. Disconnect the MAIN antenna cable (yellow-color) from the LTE MAIN pin
(Figure 1-19).
3. Disconnect the AUX antenna cable (blue-color) from the LTE AUX pin (Figure 1-19).
4. Remove one (1) screw securing the LTE module in place (Figure 1-19).
Figure 1-19. LTE Module Removal
A
AUX
MAIN
