1-22 Disassembly Procedures
5. Using the screwdriver, push the guide pins (D) firmly to release them from the top
assembly (Figure 1-28).
6. With one hand is placed underneath the touchpad module, push the touchpad
module slightly to disengage it from the bottom latches (E), and then remove the
touchpad module (F) from the top assembly (Figure 1-28).
Figure 1-28. Touchpad Board Removal
D
E E
F
WEEE Annex VII Component: Touchpad Module
